Metal Engraving Laser Machine Laser Labeling Machine

1.Product introduction ofLaser Labeling Machine:

Due to the extremely small focus spot and the small processing heat-affected zone, the ultraviolet laser can be used for ultra-fine marking and special material marking. It is the first choice for customers who have higher requirements for marking effects. In addition to copper materials, ultraviolet lasers are suitable for processing a wider range of materials. Not only the beam quality is good, the focused spot is smaller, and ultra-fine marking can be realized; the scope of application is wider; the heat-affected area is extremely small, there will be no thermal effect, and there will be no material burning problem; the marking speed is fast and the efficiency is high; the performance of the whole machine Stable, small size, low power consumption and other advantages. It is mainly used for ultra-fine marking and engraving, and is especially suitable for marking food and pharmaceutical packaging materials, drilling micro-holes, high-speed division of glass materials.

2.Technical parameters of Laser Labeling Machine:

Technical Indicators		WM-ZGJG
Laser parameters	laser	UV laser
	Laser wavelength	355nm
	Average output power	3W/5W/10W
	Laser life	100000Hour
	Modulation frequency range	20kHz~80kHz
Mirror parameters	Maximum Linear Speed	8000mm/s
	resolution	0.001mm
	Repeatability	0.003mm
Optical Output Characteristics	Marking range	F=160mm,scope175*175mm
	Minimum Line Width	0.01mm
	Minimum character height	0.2mm
cooling system	cooling method	Precise temperature control of high-efficiency water chiller
system property	laser power supply	0.5KW/AC220V/50Hz
	Optical path lifting platform	(cabinet type)
	Environmental requirements	0~25°C, humidity≤90%
